1.8M Full High Turnstile with 304 Stainless Steel Construction and IP54 Protection for Secure Dual Lane Entry

  • 1.8M Full High Turnstile with 304 Stainless Steel Construction and IP54 Protection for Secure Dual Lane Entry
  • 1.8M Full High Turnstile with 304 Stainless Steel Construction and IP54 Protection for Secure Dual Lane Entry
  • 1.8M Full High Turnstile with 304 Stainless Steel Construction and IP54 Protection for Secure Dual Lane Entry
  • 1.8M Full High Turnstile with 304 Stainless Steel Construction and IP54 Protection for Secure Dual Lane Entry
Lugar de origen Cantón, China
Nombre de la marca Goldantell/OEM
Número de modelo Serie GAT-619
Cantidad de orden mínima 2
Precio $1,106-1,855

Póngase en contacto conmigo para muestras y cupones gratis.

¿Qué es?:0086 18588475571

Veloz: 0086 18588475571

¿ Qué pasa?: sales10@aixton.com

Si tiene alguna preocupación, ofrecemos ayuda en línea las 24 horas.

x
Datos del producto
Control de acceso Tarjeta RFID, código QR Velocidad de barrera 0,2 s
Interfaz de comunicación RS-232, RS485, TCP/IP Dirección de funcionamiento De 2 vías
motor de barrera Motor sin escobillas Nivel de protección IP54
Función del girador Anti-pellizco, Prevención de colisiones, Anti-Tailgating Dimensión 1400*310*1000 mm (largo x ancho x alto)
Tipo de visualización Pantalla LCD ancho de carril 55-130cm
Fuente de alimentación AC 110 ~ 240V 10% 50/60Hz Material de alojamiento Acero inoxidable 304
Material del brazo Acrílico de 10 mm, vidrio templado o acero Sensores infrarrojos 6 ~ 10 pares
Caudal 40 personas/min (abiertos), 35 personas/min (cerrados)
Resaltar

1.8M Full High Turnstile

,

304 Stainless Steel Turnstile

,

IP54 Protection Turnstile
Deja un mensaje
Descripción de producto
Dual Lane Entry Staff Time Attendance System with 1.8M Full High Turnstile NFC Reader Turnstiles
Staff Time Attendance 1.8meter Full High Turnstile NFC Reader Double Lane Entry System
Full High Turnstile Features
  • Goldantell intelligent series turnstile gates with excellent design and performance, utilizing innovative technology and high-quality materials
  • Electric control with DC motor for stable, reliable operation and low failure rate
  • Ultra-high light traffic indicator with directional instructions using bright LED lights
  • Compatible with Face, thermal, RFID, fingerprint, QR/barcode, and ESD access control systems
  • Custom OEM/ODM services available for size, shape, and other specifications
  • Constructed with 304 stainless steel, IP54 waterproof rating, elegant anti-rust design
Full High Turnstile Specifications
Specification Details
Cabinet dimension 1400 (L) x 310 (W) x 1000 (H) mm
Cabinet material 304 stainless steel (316 ss can be custom-made)
Switching power supply AC220±10%V 50Hz or AC110±10%V 60Hz
Opening/closing time 0.2s
Arm material Thickness 10mm Acrylic, or tempered glass or steel (custom)
Access mode Single in/out or Bidirectional
Passthrough Width 900mm (or custom)
Mechanism DC Brushed motor+Clutch (or Servo motor)
Communication interface RS485, TCP/IP
Infrared sensor 6~10 pairs
Optimal flow rate 40 persons/min (open), 35 persons/min (closed)
Reset time after break down Default 10s (adjustable)
MCBF 5,000,000 Cycles
Working humidity 30%~95%
1.8M Full High Turnstile with 304 Stainless Steel Construction and IP54 Protection for Secure Dual Lane Entry 0
Security Features
  • Multi alarm modes: illegal intrusion, anti-intrusion, anti-follow, overtime alarm
  • Bi-directional or single way operation options
  • Auto-open gate during power failure to meet fire protection requirements
  • Anti-Tail gaiting feature to prevent unauthorized entry
  • Wings open automatically during power interruption
  • Fast opening and closing time
  • Built-in mechanical lock to prevent forced opening
  • Multiple pairs of IR sensors
Ideal for:
  • Banks
  • Fitness Gyms
  • Factories
  • Hotels
  • Movie theaters
  • Office buildings
1.8M Full High Turnstile with 304 Stainless Steel Construction and IP54 Protection for Secure Dual Lane Entry 1
Frequently Asked Questions
Can I have a system that only supports ESD test without software?
Yes, there are more options available. Our catalog can help you make a choice.
What language versions are available for the software system?
English and Chinese versions are available.
Can I get a software manual or installation instructions?
Yes, English version manuals are available.
Can I customize the system?
Yes, we offer OEM/ODM services with extensive experience in government projects.
What are your payment terms?
100% payment before shipment. We provide photos/videos of products before final payment.
What are your delivery terms?
EXW, FOB, CFR, CIF, DDU available.
Packing Details
  • Exported product: Wooden case package with pearl wool and plastic wrap
  • Domestic: Bubble wrap plus carton or pearl wool plus wooden packaging
  • Professional, environmentally friendly packaging services provided
Company Information
Shenzhen Goldantell Technology Co.,Ltd is a leading exporter and supply chain service provider of intelligent turnstile, access control system and parking management products since 2007. We offer customized products and OEM services with new designs developed annually.
1.8M Full High Turnstile with 304 Stainless Steel Construction and IP54 Protection for Secure Dual Lane Entry 2 1.8M Full High Turnstile with 304 Stainless Steel Construction and IP54 Protection for Secure Dual Lane Entry 3
Our Services & Strength
  • Professional OEM/ODM design services
  • CE approved with European government project experience
  • Experienced sales team with 4+ years in turnstile trade
  • Competitive pricing with high quality standards
  • Custom products and access control systems available
1.8M Full High Turnstile with 304 Stainless Steel Construction and IP54 Protection for Secure Dual Lane Entry 4
Our Pre-sale & After-sale Service
  • Pre-sale: Detailed product information and consultation
  • On-purchase: Production updates with photos and testing videos
  • After-sale: Installation guides and manuals provided
  • OEM/ODM: Custom logo, size, color options
  • Professional support: 16-hour response time
