QR Code Card Reader Tripod Turnstile with 0.4s Barrier Open/Close Time and 3 Million Operations Life

  • QR Code Card Reader Tripod Turnstile with 0.4s Barrier Open/Close Time and 3 Million Operations Life
  • QR Code Card Reader Tripod Turnstile with 0.4s Barrier Open/Close Time and 3 Million Operations Life
  • QR Code Card Reader Tripod Turnstile with 0.4s Barrier Open/Close Time and 3 Million Operations Life
  • QR Code Card Reader Tripod Turnstile with 0.4s Barrier Open/Close Time and 3 Million Operations Life
  • QR Code Card Reader Tripod Turnstile with 0.4s Barrier Open/Close Time and 3 Million Operations Life
  • QR Code Card Reader Tripod Turnstile with 0.4s Barrier Open/Close Time and 3 Million Operations Life
Lugar de origen Cantón, China
Nombre de la marca Goldantell/OEM
Número de modelo GAT-305
Cantidad de orden mínima 2
Precio $880

Póngase en contacto conmigo para muestras y cupones gratis.

¿Qué es?:0086 18588475571

Veloz: 0086 18588475571

¿ Qué pasa?: sales10@aixton.com

Si tiene alguna preocupación, ofrecemos ayuda en línea las 24 horas.

x
Datos del producto
Tipo de control de acceso Sistema ESD, Huella Digital, Tarjeta RFID Tiempo de apertura de la barrera 0,4 s
Interfaz de comunicación RS-232, RS485, TCP/IP Dirección de funcionamiento De 2 vías
motor de barrera Motor cepillado Función del girador Evitar las colisiones
Temperatura de funcionamiento -10 ℃ -60 ℃ Calificación impermeable IP54
Fuente de alimentación CA 220 V/110 V, 100 ~ 240 V Las dimensiones de las viviendas 1200 * 280 * 1000m m
Material Acero inoxidable 304 Longitud del brazo 51 cm
Ancho de pase 600 mm Motor de transmisión Válvula electromagnética de DC24V
Vida corriente normal 3 millones
Resaltar

QR Code Card Reader Tripod Turnstile

,

0.4s Barrier Open/Close Time Security Turnstile Gate

,

3 Million Operations Life Access Control Turnstile
Deja un mensaje
Descripción de producto
QR Code Card Reader Half Height Double Face Recognition Mechanism Tripod Turnstile Zk
Standard Working Performance
  • Turnstile can be configured by pressing the button on the main control board
  • Auto-lift-arm function: For fully automatic models, the arm lifts automatically with alert when power is restored
  • Auto-drop-arm function: The arm drops down automatically (default) or allows free passage when power is off
  • Automatic Reset Functions: Cancels authorization if user doesn't pass within set time (adjustable 1-60s)
  • Compatible with various systems: door access control, consumption systems, biometric recognition, ESD systems
Technical Parameters
Size of housing 1200 L * 280 W * 1000 H (mm) Material 304 stainless steel
Direction Single or bi-directional (optional) Arm length 51cm
Pass width 600mm Waterproof IP54
Power Supply 100~240 volt Drive motor DC24V solenoid valve
LED light Direction arrow (optional) Normal running life 3 million cycles
QR Code Card Reader Tripod Turnstile with 0.4s Barrier Open/Close Time and 3 Million Operations Life 0 QR Code Card Reader Tripod Turnstile with 0.4s Barrier Open/Close Time and 3 Million Operations Life 1
Key Features
  • Low noise operation with no mechanical impact
  • Single or bi-directional configuration options
  • High-speed operation with quick response
  • Premium design with durable construction
  • Robust, rigid, anti-rust and long-lasting
  • Smooth working system with self-test function
Additional Functions
  • Counting function available (counter)
  • Information display option (LCD screen)
  • Audible sound prompt (speaker)
  • Invalid entry alarm
  • Auto-lift-arm function (full automatic models)
Typical Applications
Subway Stations, Airports, Tourism Sites, Sports Venues, Exhibitions, Swimming Pools, Residential Areas, Corporate Entrances, Attendance Systems, Security Checkpoints, Fee Management, Special Access Control
QR Code Card Reader Tripod Turnstile with 0.4s Barrier Open/Close Time and 3 Million Operations Life 2 QR Code Card Reader Tripod Turnstile with 0.4s Barrier Open/Close Time and 3 Million Operations Life 3
Our Service Commitment
  • Pre-sale: Detailed product information and consultation
  • During purchase: Production updates with photos and testing videos
  • After-sale: Installation guides, manuals, and instructional videos
  • Customization: OEM/ODM services including logo, size, and color
  • Support: 16-hour response window for inquiries
Frequently Asked Questions
Q: Can your machine work with our card reading system or other access systems?
A: Yes, our turnstiles are compatible with various access control systems.
Q: Can your machine work with Turnstile Doors?
A: Absolutely, integration with turnstile doors is supported.
Q: Is after-sale support available?
A: Yes, we provide warranty service plus ongoing technical support.
Q: Does your machine support WiFi?
A: Yes, we support Wired, WiFi, and 4G module connections.
Q: What is your production lead time?
A: Standard items: 7-15 working days depending on quantity. Custom items require 3-10 additional days.
About Goldantell
Shenzhen Goldantell Technology Co., Ltd is a leading manufacturer of intelligent turnstiles, access control systems, and parking management solutions since 2007. We specialize in customized products and OEM services, with new designs introduced annually.
QR Code Card Reader Tripod Turnstile with 0.4s Barrier Open/Close Time and 3 Million Operations Life 4 QR Code Card Reader Tripod Turnstile with 0.4s Barrier Open/Close Time and 3 Million Operations Life 5
Why Choose Goldantell?
  • 13+ years specializing in turnstile technology
  • Full customization services including OEM/ODM
  • Cost-optimized designs without compromising quality
  • Rapid response time with project solutions
